Introducing the Topping D90LE DAC: Unleash the Ultimate in Audiophile Performance. Elevate your audio experience to new heights with the Topping D90LE DAC, a masterpiece of sound engineering. At the core of this exceptional DAC lies the ESS Sabre ES9038Pro, the flagship DAC chip renowned for its 32-bit Hyper-Stream architecture, delivering unparalleled audio performance. Step into the realm of audio excellence with the D90LE, where every note is crystal clear and every nuance is faithfully reproduced.
What sets the D90LE apart is its innovative design featuring parallel arrangement of four conventional balanced channels for each channel. This unique configuration takes audio performance to the next level, ensuring that the D90LE outshines the competition.
But that's not all. The D90LE takes a revolutionary step in sound simulation by incorporating the harmonics of tubes and transistors. Topping has harnessed cutting-edge technology to bring you three distinct sound profiles, allowing you to tailor your listening experience to your preference.
Whether you have a preamp with adjustable balance control or not, the D90LE has you covered. Its balanced support functions give you the flexibility to fine-tune your audio, ensuring an optimal listening experience.
Versatility is at the heart of the D90LE's design. With multiple input options, it seamlessly integrates into a wide range of audio systems. Connect via AES, USB-B (XMOS), Coaxial, Toslink Optics, or I2S LVDS via HDMI. The I2S LVDS input even offers selectable modes to adapt to your specific LVDS devices. The D90LE's output options include unbalanced RCA Stereo and balanced XLR, and you have the flexibility to use one or both outputs at your convenience.
To top it all off, the D90LE boasts an integrated volume control, functioning as a preamplifier. The volume control can be disabled if you prefer the D90LE to operate solely as a DAC, maintaining output levels at their peak performance – 4 Volts for XLR and 2 Volts for RCA.
Elevate your audio experience with the Topping D90LE DAC. It's not just a product; it's a gateway to audiophile nirvana. Discover the nuances, revel in the details, and immerse yourself in a world of sound that's true to its source. Experience audio like never before with the Topping D90LE.
Introducing the Topping D90LE DAC: Unleash the Ultimate in Audiophile Performance. Elevate your audio experience to new heights with the Topping D90LE DAC, a masterpiece of sound engineering. At the core of this exceptional DAC lies the ESS Sabre ES9038Pro, the flagship DAC chip renowned for its 32-bit Hyper-Stream architecture, delivering unparalleled audio performance. Step into the realm of audio excellence with the D90LE, where every note is crystal clear and every nuance is faithfully reproduced.
What sets the D90LE apart is its innovative design featuring parallel arrangement of four conventional balanced channels for each channel. This unique configuration takes audio performance to the next level, ensuring that the D90LE outshines the competition.
But that's not all. The D90LE takes a revolutionary step in sound simulation by incorporating the harmonics of tubes and transistors. Topping has harnessed cutting-edge technology to bring you three distinct sound profiles, allowing you to tailor your listening experience to your preference.
Whether you have a preamp with adjustable balance control or not, the D90LE has you covered. Its balanced support functions give you the flexibility to fine-tune your audio, ensuring an optimal listening experience.
Versatility is at the heart of the D90LE's design. With multiple input options, it seamlessly integrates into a wide range of audio systems. Connect via AES, USB-B (XMOS), Coaxial, Toslink Optics, or I2S LVDS via HDMI. The I2S LVDS input even offers selectable modes to adapt to your specific LVDS devices. The D90LE's output options include unbalanced RCA Stereo and balanced XLR, and you have the flexibility to use one or both outputs at your convenience.
To top it all off, the D90LE boasts an integrated volume control, functioning as a preamplifier. The volume control can be disabled if you prefer the D90LE to operate solely as a DAC, maintaining output levels at their peak performance – 4 Volts for XLR and 2 Volts for RCA.
Elevate your audio experience with the Topping D90LE DAC. It's not just a product; it's a gateway to audiophile nirvana. Discover the nuances, revel in the details, and immerse yourself in a world of sound that's true to its source. Experience audio like never before with the Topping D90LE.
Specification | RCA LINE OUT MEASUREMENTS @ USB, 96KHZ | XLR LINE OUT MEASUREMENTS @ USB, 96KHZ |
---|---|---|
Product type | Balanced DAC | Balanced DAC |
Inputs | 1x USB-B 1x AES 1x Coaxial 1x Optical Toslink 1x I2S LVDS via HDMI Bluetooth 5.0 |
1x USB-B 1x AES 1x Coaxial 1x Optical Toslink 1x I2S LVDS via HDMI Bluetooth 5.0 |
Outputs | 1x Stereo RCA 1x Stereo XLR |
1x Stereo RCA 1x Stereo XLR |
DAC Chip | ESS ES9038Pro | ESS ES9038Pro |
USB interface | XMOS XU216 | XMOS XU216 |
Supported Bluetooth codecs | SBC, AAC, aptX, aptX LL, aptX HD, LDAC | SBC, AAC, aptX, aptX LL, aptX HD, LDAC |
Supported sampling rates | PCM up to 32bit 768kHz DSD up to DSD512 |
PCM up to 32bit 768kHz DSD up to DSD512 |
THD+N @ A-Weighting | < 0.00007% @ 1kHz | < 0.00005% @ 1kHz |
THD @ No-Weighting, 90kBw | < 0.0008% @ 20Hz-20kHz | < 0.0003% @ 20Hz-20kHz |
SNR @ A-Weighting | 127dB @ 1kHz | 134dB @ 1kHz |
Dynamic range @ A-Weighting | 127dB @ 1kHz | 134dB @ 1kHz |
Frequency response | 20Hz-20kHz (±0.1dB) 20Hz-40kHz (±0.3dB) |
20Hz-20kHz (±0.1dB) 20Hz-40kHz (±0.3dB) |
Output level | 2.1Vrms @ 0dBFS (Mode 4V) 2.6Vrms @ 0dBFS (Mode 5V) |
4.2Vrms @ 0dBFS (Mode 4V) 5.2Vrms @ 0dBFS (Mode 5V) |
Noise @ A-Weighting | < 1.3µVrms | < 1.1µVrms |
Crosstalk | -124dB @ 1kHz | -139dB @ 1kHz |
Channel balance | 0.
