SoftEars Volume 1DD 2BA Reference Hybrid IEM is Softear's latest masterpiece and a new bar for mid-tier priced reference IEM. With smart innovations and unique driver configurations, Volume is a strong contender for Earphone of the Year 2022.

3-WAY HYBRID REDEFINED

Softears designed and developed a true 3-way IEM comprised of a groundbreaking dynamic driver combined with the accuracy of a nouveau mid-high BA configuration.

Unlike similar hybrid designs that use 2BA for mid/high frequencies, Softears has developed a new unique crossover for the Volume, comprising a full-range BA and a high frequency BA. The two balanced armatures are driven through a complex RC crossover circuit that immensely lowers distortion and allows for a wider frequency response than similar products.

The complex crossover is carefully engineered with 8 components and ensures stability independent of the output impedance of the source. It was designed to reduce hiss from amplifiers, yet the efficiency is high enough for use with portable devices.

NEWLY DEVELOPED BERYLLIUM-PLATED DYNAMIC DRIVER

Volume has a 10mm beryllium-plated dynamic driver that features an internal magnetic dual-chamber. The diaphragm is connected to an ultra-soft suspension with low decay. The woofer is specifically designed for low-end frequencies to deliver a powerful yet precise bass, even when driven from portable devices. Similar designs have usually only been found in large speakers or studio monitors.

BEAUTIFUL RACING GREEN DESIGN

The green metal faceplate is precisely cut from anodized aluminum with a CNC machine. CNC technology was used to match the production with the precision of the sound design.

While the classy green color might at first strike a resemblance to the golden years of racing, those who have listened to the Volume will know that the green color is actually poison. The sound of Volume is simply addicting and fits and genre, while boasting the prowess of a racing car engine.

SoftEars Volume 1DD 2BA Reference Hybrid IEM

15% OFF Selected USB DACs when purchased with any In Ear Monitor or Earphone
Shop Now
£299.00
£299.00
£299.00
Ear Tips: Standard

SoftEars Volume 1DD 2BA Reference Hybrid IEM is Softear's latest masterpiece and a new bar for mid-tier priced reference IEM. With smart innovations and unique driver configurations, Volume is a strong contender for Earphone of the Year 2022.

3-WAY HYBRID REDEFINED

Softears designed and developed a true 3-way IEM comprised of a groundbreaking dynamic driver combined with the accuracy of a nouveau mid-high BA configuration.

Unlike similar hybrid designs that use 2BA for mid/high frequencies, Softears has developed a new unique crossover for the Volume, comprising a full-range BA and a high frequency BA. The two balanced armatures are driven through a complex RC crossover circuit that immensely lowers distortion and allows for a wider frequency response than similar products.

The complex crossover is carefully engineered with 8 components and ensures stability independent of the output impedance of the source. It was designed to reduce hiss from amplifiers, yet the efficiency is high enough for use with portable devices.

NEWLY DEVELOPED BERYLLIUM-PLATED DYNAMIC DRIVER

Volume has a 10mm beryllium-plated dynamic driver that features an internal magnetic dual-chamber. The diaphragm is connected to an ultra-soft suspension with low decay. The woofer is specifically designed for low-end frequencies to deliver a powerful yet precise bass, even when driven from portable devices. Similar designs have usually only been found in large speakers or studio monitors.

BEAUTIFUL RACING GREEN DESIGN

The green metal faceplate is precisely cut from anodized aluminum with a CNC machine. CNC technology was used to match the production with the precision of the sound design.

While the classy green color might at first strike a resemblance to the golden years of racing, those who have listened to the Volume will know that the green color is actually poison. The sound of Volume is simply addicting and fits and genre, while boasting the prowess of a racing car engine.

Impedance: 5Ω@ 1kHz
Sensitivity: 123.7dB/Vrms@1kHz
Effective frequency response: 20- 20kHz (IEC60318-4)
Frequency range: 8- 40kHz(1/4 inch free field microphone, -5 dB)
THD:< 1%@ 1kHz
Shell: imported medical resin+aluminum alloy
Driver: 10mm dynamic +2 balanced armature
Dynamic diaphragm: PU flexible suspending+beryllium-plated

  • SoftEars RSV Headphones
  • 3.5mm Cable
  • Leather Carry Case
  • Cleaning cloth
  • Cleaning tool
  • Earbuds
  • Warranty
